FPVCycle 23mm Short Motor - THE Cinewhoop motor

  • Sale
  • Regular price $19.99


The update:
New look, minor tweak to internal stator design, improved low end prop handling, new prop mount, less weight, screw retained bell.  These motors are compatible with the previous 2203/4.  If you mix them on the same craft with similar kv, you won't be able to tell a difference in flight performance.

We haven't used a better performing 3" cinewhoop motor than this one...





This motor is specifically designed for the following uses:

3” ducted whoop
4” anything
5” light blade and low general AUW for 5”

Matching products:
CineSplore w/ Gemfan 75mm CineWhoop prop
PowerPick 4” with Gemfan 4023 prop
PowerPick 5” with Gemfan 5125 prop
Fouride 4” with Gemfan 4023 prop
Fouride 5” with Gemfan 5125 prop
Red T-mount props are fantastic with Gemfan 4024
3000kv version is suitable for CineWhoop/CineSplore on 6S if desired

Recommended battery options:
3
S 1000-1500mah on 3450kv with CineWhoop 3”or 4” open prop
4S 1100-1300mah on 3450kv with CineWhoop 3” or 4” open prop
3S 1100-1300mah on 3450kv with 4" or 5" open prop
4S 900-1300mah on 3450kv with 4" open prop
4S 1100-1300mah on 2350kv with 5" open prop

4S 1100-1300mah on 3450kv with CineWhoop 3”
5S 1100-1300mah on 2350kv with CineWhoop 3” or 4” open prop
6S 850-1000mah on 2350kv with CineWhoop 3”

You’re welcome to run full 4S with no throttle cut on 3450kv and 5” but be warned that it will be extremely overpowered on a very light platform and a challenge to deal with the electronic noise due to the high power.  If your filters and overall electronic management is not done right, the motors have some risk of burning.  Even though these motors have super high temperature enamel coating on the winds, we are not responsible for burnt motors due to misuse.

Specifications:

  • 23mm stator diameter, greater than 3mm stator height
  • 12x12mm M2 mounting pattern (not flush mount)
  • ~17g with ~80mm length wires
  • ~20g with prop adapter, nut and 240mm 24awg wire length
  • 0.15mm Kawasaki High performance laminations
  • N52SH ARC magnets
  • 3mm grade 5 titanium internal shaft
  • M3 grade 5 titanium prop shaft with M5 adapter
  • 3x8x4mm 683zz Japan ISC Custom bearings
  • 7075-T6 aluminum casing
  • 260℃ enamel coated single wrap oxygen-free copper windings

    Customer Reviews

    Based on 89 reviews
    94%
    (84)
    6%
    (5)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    C
    Customer (Surrey, CA)
    motors work well

    they good

    K
    Kraig Mitchell (Cranston, US)
    Extremely pleased

    These motors are doing exactly what I need them to. I’ve now got them on 3 cinewhoops and a 3.5’ little ripper. Every time they come down they’re cool. So far so good, I’m happy.

    E
    Eric Downard
    Great motors

    These have been great on my shendrone squirt. I absolutely love fpvcycle motors. I have them on almost all my quads now

    A
    Alec Hall (Columbus, US)
    No question, the best Cinewhoop motor available

    I use these on a slammed Shendrones Squirt and a Toothfairy 2 Cinewhoop, both carrying a full sized GoPro Hero 10. I run the TF2 sometimes with full ducts and Gemfan 5 blade 3" props, and the Shendrones squirt with slammed ducts and HQ 6 bladed props. Both are very very smooth, the motors are very smooth and stable and don't get hot even in outdoor flying fighting wind and direction changes.

    L
    Luis G. (Besançon, FR)
    Great motor, but for a sub250 I nowdays would buy the 21mm

    Love the motor!
